Covering the most needs and applications, these systems are available in a vast number of sizes. With a proven track record of reliability and quality, multiple years of research has led to this comprehensive range of systems and speciality components.
District Heating, Hot Water and Cooling Applications
We specialise in high-quality fusion welded joints on steel pipes, and that is why we insist on installing only the best pipes and pipe-related accoutrements in the industry. For this, we trust LOGSTOR.
Having been ISO 9001 registered since 1992, it is LOGSTOR`s mission to create and manufacture pre-insulated piping products which will provide trouble-free service over many years.
The LOGSTOR district heating system is designed for use with media ranging in temperature between 0°C and 120°C with the typical most common application being district heating. The system can, however, be utilised with other types of fluid media. Enclosed in high-density polyethylene jackets, it features polyurethane insulation with unique properties which ensure low operational expenditure.
Carrier Pipes
District heating pipes are available in both straight or flexible pipes in the following compositions:
- Straight carrier pipes: Steel P235GH and Copper
- Flexible carrier pipes: Steel, PEX, PE-RT-alu-PE-RT and Copper
While the full technical details of each type of carrier pipe can be found at the LOGSTOR website, the following technical specifications will provide you with a basic overview.
Steel P235GH
- High-frequency welded P235GH, complying with EN 253
- Testing pressure min. 50 bar or eddy-current test
- Supplied in lengths of 6, 12 and 16 m
- Sizes DN 20 to DN 1200
Special Carrier Pipes
Carrier pipes in other qualities and made to comply with alternative standards can be requested.
